541 TECHNICAL SPECIFICATIONS

PLEASE NOTE: Specifications tabulated here are actual, real-world measurements, not optimistic allusions to theoretical ideals. Measurement results should be repeatable when using the appropriate, laboratory-grade test equipment.

RF & RECEPTION

• Tuning Range: Tunes 76.0 MHz–108.0 MHz in 100 kHz steps.
• Antenna Input: 75-ohm (F), 1 VRMS max.
• High Level RF Input: 50-ohm (BNC), 5 VRMS max.
• Off-Air Sensitivity (for 50 dB monaural SNR):
  5 dBµV or better with de-emphasis.
  15 dBµV or better unweighted.
• Reception Modes: Stereo / Forced Mono / SCA Program Audio

FM BASEBAND

(Off-Air or High Level; (D) indicates measurements taken with de-emphasis.)

• Frequency Response: ±0.25 dB, 10 Hz–100 kHz.
• Signal-to-Noise (D): >83 dB.
• Distortion (D): <0.01% THD+N; <0.01% IMD (SMPTE, 60 Hz/7 kHz, 4:1).
• FM Deviation: Indicates composite (total) and independent positive and negative deviations.
  ±75 kHz = 100% Modulation; 0–200% metering with ±1% accuracy.
• AM Noise (D): Measures down to 87 dB below 100% AM Modulation.
• FM Stereo Pilot: Indicates 0–15% pilot injection; pilot frequency readout has ±0.1 Hz accuracy.
• FM Subcarriers: Indicates percent injection of 38 kHz (residual), 57 kHz RDS, 67 kHz/92 kHz SCA subcarriers.

FM AUDIO PERFORMANCE

(Off-Air or High Level; taken with de-emphasis.)

• Frequency Response: ±0.1 dB, 20 Hz–15 kHz

• Signal-to-Noise:

  • Analog Out: >90 dB
  • Digital Out: >90 dB

• Distortion:

  • Analog Out: <0.01% THD+N; <0.02% IMD (SMPTE, 60 Hz/7 kHz, 4:1).
  • Digital Out: <0.01% THD+N; <0.01% IMD (SMPTE, 60 Hz/7 kHz, 4:1).
• Stereo Separation: >64 dB, 20 Hz–15 kHz
• FM Stereo Crosstalk (Main→Sub or Sub→Main): >67 dB, 20 Hz–15 kHz.
• FM De-emphasis: 75 µs / 50 µs / None.

INPUTS, OUTPUTS AND PORTS

• MPX Output: (BNC) Select either MPX or 19 kHz stereo pilot sample; adjustable from 1 VPP to 6 VPP in 0.01 V steps; ±0.25 dB, 10 Hz–100 kHz.

• Program Audio Outputs: May be assigned to the FM-stereo program or to SCA audio. Unless otherwise noted, performance parameters reflect FM Stereo Performance cited above.

  • Balanced Analog: (XLR) Left and Right outputs adjustable from –15 dBu to +15 dBu in 0.1 dB steps; 600 Ω resistive source.
  • AES Digital: (XLR) Adjustable from –30 dBFS to 0 dBFS in 0.1 dB steps; user-selected 44.1 kHz or 48 kHz sample rate; 110 Ω transformer-coupled.
  • Dante/AES67 Compatible AoIP Port: (RJ45) Output at 44.1 kHz (Dante-only) or 44.1 kHz/48 kHz (Dante/AES67); AoIP utility has independent IP, Audio Format and Transmit Flow settings; level adjustable from –30 dBFS to 0 dBFS in 0.1 dB steps.
  • UDP Stream: ADTS or ADTS in MPEG-TS transport.
  • HTTP/Icecast ‘Casual’ Listening Stream: Web browser remote-listening stream employs HE-AACv2 encoding, 44.1 kHz or 48 kHz sample rate, bit-rates from 18 kbps to 64 kbps; accommodates up to 10 simultaneous listeners. HTTP/Icecast and raw UDP streams are available simultaneously.
• Headphone Jack: (¼” TRS) Menu-adjustable listening level.
• LAN Port: (RJ45) LAN connection to local network or Internet provides remote monitoring, control, listening and full SNMP implementation; user-programmable network setup and streaming parameters.
• General Purpose Outputs: (Barrier Strip) Six individual open-collector NPN transistor closures to ground are associated with alarm functions. Each is programmable for GPO assignment and logic polarity. Outputs sink 100 mA, 40 Vdc max.

DISPLAYS AND DISPLAY OPTIONS

• Bargraph & Numerical Level Metering: Carrier Modulation • Stereo Pilot & Subcarriers • MPX Power • Demodulated L/R & L+R/L–R • Stereo Separation • Stereo Crosstalk • BS.1770 Loudness • SCA Levels • Synchronous & AM Noise.
• Graphic Displays and History Plots: IF Spectrum • MPX Spectrum • Audio Spectrum • Audio Oscilloscope • Audio XY • FM Modulation History • Audio Level History • RF Metrics History • BandScanner™ utility.
• RDS Fields Displayed: PS • PI • Call • RT • RT+1 • RT+2 • PTY • PTYN • CT • M/S • DI • TP • TA • AF • ODA • Block Error Rate • Groups & Group Use Statistics.

TIMEKEEPING AND ALARMS

• Real-Time Clock: Auto-sets to Internet time; auto/manual DST setting; battery backup.
• Local & Remote Alarms: Carrier Overmod • MPX Power • Audio Loss • Low Signal • Pilot Loss • Multipath • RDS Loss • RDS PI Error • RDS RT • RDS CT • RDS TMC • Pilot Loss • MPX Power • FSK ID Error.
  (Most alarms have multiple parameter settings. All alarms can send text or email notifications. Alarms are automatically logged daily, weekly and monthly.)

POWER, ENVIRONMENTAL, MISCELLANEOUS

• Power Requirement: 88–264 VAC, Single-Phase; 12 W.
• AC Mains Power Factor: Better than 0.6 / 0.9*
  *Upon customer request
• Operating Environment: 32 °F / 0 °C – 122 °F / 50 °C; 0 %–95 % non-condensing relative humidity; 10,000 ft / 3048 m.
• Size and Weight: 3.5″ H × 19″ W × 9″ D; 12 lbs. shipping weight.
• Conformances: EN50081-1 / EN50082-1 • 93/68/EEC • 2002/95/EC
